¥86,028 JPY ¥101,199 JPY
| /
| Brand | TEIN |
| Series Name | STREET BASIS Z COILOVER SUSPENSION KIT |
| Product Number | GSC86-81AS2 |
| Compatible Car | TOYOTA VELLFIRE GGH20W |
| Product Description | Model year: 2008.05-2014.12 Engine/Drive system: 3500 FF Model: GGH20W Grade: 3.5V L-EDITION, 3.5Z G-EDITION Springs included: Yes EDFC compatible: - Damping force adjustment (F/R): -/- Overall length adjustment (F/R): -/- Mount (F/R): - STD/- STD Standard vehicle height compared to factory (F/R): -45/-50 Standard spring rate (N/mm / Kgf/mm) (F/R): 49.0/5.0 / 58.8/6.0 Standard spring free length (mm) / Inner diameter (mm): 275/- / 257/- |
| Remarks | [Notes] RR genuine dust boots need to be modified. When adjusting the RR ride height, the HAS needs to be removed from the vehicle. |
| Notes | Images are for illustration purpose only. Actual product may vary. |
