¥92,902 JPY ¥99,000 JPY
| /
| Brand | KAMEARI |
| Series Name | A 12 MODIFIED 77Φ LIGHTWEIGHT RACING PISTON (FORGED + MACHINED) |
| Product Number | KAMEARI-01397 |
| Compatible Car | |
| Product Description | This piston is made from forged material, which has a proven track record of durability, and is as lightweight as possible. In addition to a 7mm wide top land design, the valve recess is carved to 4.5mm for both the IN and EX to accommodate high lift camshafts. Furthermore, the design incorporates the durability and high performance required for racing, such as changes to the ovality and skirt shape. Manufacturing method: Forged + machined Type: High compression Piston diameter: φ77 (STD/OS) Pin diameter:✕Length φ17.45✕ 46mm Pin height 32.7mmPiston ring thickness 1.2✕1.2✕2.5mm round thickness 7.0✕3.5✕2.9mm Recess depth IN4.5/EX4.5mm Recess volume 2.6cc Weight 234g |
| Remarks | Piston diameter (design value) 77φ (STD) = 76.93φ 77φ (OS) = 76.98φ 37 |
| Notes | Images are for illustration purpose only. Actual product may vary. |
