¥22,709 JPY ¥24,200 JPY
| /
| Brand | KAMEARI |
| Series Name | KAMEARI L-TYPE REINFORCED MAIN STUD BOLT KIT L4 |
| Product Number | KAMEARI-00083 |
| Compatible Car | |
| Product Description | One of the effective ways to suppress crank vibration that occurs at high revolutions and high loads is to use stud bolts. This allows the cylinder block threads to be used all the way to the back, and allows for high tightening torque. In addition, stress is distributed throughout the threads, minimizing deformation of the housing and reducing damage to the metal. Reinforced stud bolts: Kameari Chromoly SCM435 Reinforced nuts: ARP No. 100-9908 (M10 x P1.25) Reinforced washers: Kameari OD 22 x ID 11 x thickness 3.0 (Reference: OD: ARP = 20) Wrench size: M12 12-sided Molybdenum grease: ARP No. 100-9908 Nut tightening torque: 8.3-10kgf・m (with ARP grease) 81.4-98N・m (with ARP grease) |
| Remarks | *This product addresses the problem of the bolt tip touching the oil pan, which occurred with conventional stud bolts. (Note) Line boring may be required if the bolt is tightened beyond 8.3kgf・m (81.4N・m). *Bolt installation torque: Hand tightening (no oil) *The nut and molybdenum grease are ARP products. 14 |
| Notes | Images are for illustration purpose only. Actual product may vary. |
