¥95,379 JPY ¥112,200 JPY
| /
| Brand | TEIN |
| Series Name | STREET ADVANCE Z4 COILOVER SUSPENSION KIT |
| Product Number | VSUC2-G1BS2 |
| Compatible Car | SUZUKI JIMNY SIERRA JB74W |
| Product Description | Model year: 2018.07+ Engine/Drive system: 1500 4WD Model: JB74W Grade: JC,JL Springs included: Yes EDFC compatible: - Damping force adjustment (F/R): Yes/Yes Overall length adjustment (F/R): -/- Mount (F/R): - STD/- STD Standard vehicle height compared to factory (F/R): 25/20 Standard spring rate (N/mm / Kgf/mm) (F/R): 22.6/2.3 / 23.1/2.4 Standard spring free length (mm) / Inner diameter (mm): 333/- / 292/- |
| Remarks | [Notes] The vehicle height can be adjusted in two stages using spacers. FT: When installing the shock absorber, please check the tightening torque in the instruction manual included. Over-torque tightening may cause the piston rod to break. RR: There are left and right springs, so be careful not to install them incorrectly. |
| Notes | Images are for illustration purpose only. Actual product may vary. |
