¥100,054 JPY ¥117,700 JPY
| /
| Brand | TEIN |
| Series Name | 4X4 DAMPER SPORT COILOVER SUSPENSION KIT |
| Product Number | VSUC2-F1SS2 |
| Compatible Car | SUZUKI JIMNY JB64W |
| Product Description | Model year: 2018.07+ Engine/Drive system: 660 4WD Model: JB64W Grade: XC, XL, XG Springs included: Yes EDFC compatible: - Damping force adjustment (F/R): Yes/Yes Overall length adjustment (F/R): -/- Mount (F/R): - STD/- STD Standard vehicle height compared to factory (F/R): 55/40 Standard spring rate (N/mm / Kgf/mm) (F/R): 24.5/2.5 / 21.6/2.2 Standard spring free length (mm) / Inner diameter (mm): 366/- / 333/- |
| Remarks | [Notes] Since the safety standards (front-view and side visibility standards) will no longer be met, it is necessary to add a forward visibility confirmation mechanism such as a mirror or front view camera. Replacement of the brake hose and locking hose is required for installation. (Brake hose recommended: 50mm longer than genuine) We also recommend replacing the caster correction bush and lateral rod. The vehicle height cannot be adjusted. FT: When installing the shock absorber, please check the tightening torque in the enclosed instruction manual. Over-torque tightening may cause the piston rod to break. RR: There are left and right springs, so be careful not to install them incorrectly. |
| Notes | Images are for illustration purpose only. Actual product may vary. |
