¥122,497 JPY ¥144,100 JPY
| /
| Brand | TEIN |
| Series Name | 4X4 DAMPER SPORT COILOVER SUSPENSION KIT |
| Product Number | VSTC2-F1SS2 |
| Compatible Car | TOYOTA HILUX GUN125 |
| Product Description | Model year: 2017.10-2020.07 Engine/Drive system: 2400 4WD Model: GUN125 Grade: Z, X Springs included: Yes EDFC compatible: Yes Damping force adjustment (F/R): Yes/Yes Overall length adjustment (F/R): -/- Mount (F/R): - STD/- STD Standard vehicle height compared to factory (F/R): 40/40 Standard spring rate (N/mm / Kgf/mm) (F/R): 117.6/12.0 / /- Standard spring free length (mm) / Inner diameter (mm): 325/- / /- |
| Remarks | [Notes] Please use with vehicle height that complies with safety standards (total height within ±40MM). Since the safety standards (immediate and side visibility standards) will no longer be met, it is necessary to add a forward visibility confirmation mechanism such as a mirror or front view camera. If the standard (height 550MM) for the intrusion prevention device (rear bumper) is not met, the rear bumper position will need to be adjusted. When lifting up the rear, it is necessary to move the back fog lights to a position within the safety standards or remove them. The rear cannot be adjusted for vehicle height. |
| Notes | Images are for illustration purpose only. Actual product may vary. |
