¥86,028 JPY ¥101,199 JPY
| /
| Brand | TEIN |
| Series Name | STREET BASIS Z COILOVER SUSPENSION KIT |
| Product Number | GSC78-81AS2 |
| Compatible Car | TOYOTA VELLFIRE GGH20W |
| Product Description | Model year: 2008.05-2014.12 Engine/Drive system: 3500 FF Model: GGH20W Grade: 3.5V, 3.5Z, 3.5X Springs included: Yes EDFC compatible: - Damping force adjustment (F/R): -/- Overall length adjustment (F/R): -/- Mount (F/R): - STD/- STD Standard vehicle height compared to factory (F/R): -55/-50 Standard spring rate (N/mm / Kgf/mm) (F/R): 39.2/4.0 / 58.8/6.0 Standard spring free length (mm) / Inner diameter (mm): 275/- / 248/- |
| Remarks | [Notes] RR: Requires modification of the genuine dust boot. RR: When adjusting the vehicle height, the HAS must be removed from the vehicle. For vehicles equipped with manufacturer's options (twin moonroof, power back door, etc.), the vehicle height may be lower than the standard value due to the increased weight, so we recommend part number "GSC86-81AS2". (Estimated vehicle weight: 2,000 kg or more) |
| Notes | Images are for illustration purpose only. Actual product may vary. |
