¥26,322 JPY ¥28,050 JPY
| /
| Brand | KAMEARI |
| Series Name | KAMEARI REINFORCED HEAD STUD BOLT L4 SET |
| Product Number | KAMEARI-00267 |
| Compatible Car | |
| Product Description | By using stud bolts, the cylinder block threads can be used all the way to the back. This distributes the stress generated by tightening over the entire thread, reducing cylinder deformation by about half and improving accuracy. In addition, the use of large diameter washers increases the contact area, ensuring that the tightening force is transmitted over a wide area. Stud bolts: Kameari Chromoly SCM435 Kameari washer: Outer diameter 22 x inner diameter 11 x thickness 3.0 (reference outer diameter: ARP=20) Nut: ARP M10 x P1.25 Wrench size: M12 12-sided Molybdenum grease: ARP No. 100-9908 Tightening torque: 8.3 kgf-m (with ARP grease) 81.4 N-m (with ARP grease) *Bolt installation torque: Hand tightening (without oil) |
| Remarks | *Nuts and molybdenum grease are ARP products included. 20 |
| Notes | Images are for illustration purpose only. Actual product may vary. |
