¥82,579 JPY ¥88,000 JPY
| /
| Brand | GANADOR |
| Series Name | DOUBLE PIPE EXHAUST POLISHED |
| Product Number | PAS-104 |
| Compatible Car | TOYOTA PRIUS 6LA-MXWH61 |
| Compatible Engine | M20A-1VM |
| Product Description | ◆Model name: Prius◆Compatible grades etc.: PHEV Z grade (plug-in hybrid)◆Compatible vehicle model: 6LA-MXWH61 (2WD)◆Engine type: M20A-FXS/1VM (1,986cc Hybrid)◆Compatible Year: R5.3~◆Brand Series: PASION EVO (equipped with PBS.S)◆Part number: PAS-104◆Idling volume (dB): GD: 67.0 (OEM: 58.0)◆Nearby exhaust noise (dB): GD: 87.0 (OEM: 72.0) *Measured at 2,500 rpm due to rotation limiter operation.◆Power (PS): GD: 242.8 (OEM: 232.3)◆Torque (kgf・m): GD: 35.6 (OEM: 31.0)◆Muffler weight (kg): GD: 10.3 (OEM: 10.9)◆Muffler ground clearance (empty vehicle): Bottom of piping (rear of front pipe): 15.0cm / Bottom of tail: 15.0cm / Bottom of silencer: 21.0cm - *Development vehicle data: Normal vehicle height (below are measurements from the ground) - Front fender arch: 710mm / Rear fender arch: 710mm◆Tail Diameter: 105×70φ Oval (Double right exit)◆Pipe Diameter: 50φ◆Accessory parts: G28 gasket (1 piece), M10 flange nut (1 piece), M8X35 washer bolt & M8 flange nut set (3S), earth line 200mm (1S), instruction manual◆Genuine reused product: Taper gasket (1 piece), special bolt and spring (2S), rubber mount (4 pieces)◆Important Notes: *Various aero parts are not confirmed. - *The silencer is a woolless type. |
| Notes | Images are for illustration purpose only. Actual product may vary. |
