RECARO BASE FRAME SEAT RAIL SPORTS RIGHT SEAT FOR TOYOTA GR YARIS GXPA16 MXPA12 2080.024.2

RECARO

SPORTS BASE FRAME SEAT RAIL RIGHT SEAT  (One Position: Low)

2080.024.2

TOYOTA GR YARIS GXPA16 MXPA12

YEAR MODEL: 2020/07-
The genuine seat built-in side airbag function will disappear. Work required to turn off the airbag warning light. The seating position is about 18 mm higher than the lowest position of the genuine seat height adjustment function when using the adapter frame (20 mm lower when not using the adapter frame). (When using New LX-F). The steering wheel offset of the RECARO seat is about 20mm from the center of the steering wheel toward the door (6mm closer to the door than the genuine seat). The slide amount is 40mm shorter than the genuine one. If a RECARO seat without SBR is installed in the passenger seat, the occupant detection sensor will not function and the seat belt warning light will not illuminate, but if the RECARO seat with SBR is installed, the function can be maintained as it is.
New structural frame. One position type.
Matching Information: LX / LX-# / LX-VS / LX-VF / LX-VL / Ergomed / Ergomed C / Ergomed D / Ergomed E / Ergomed LD / Ergomed MV (IS-84 based) : o
LX-F (based on IS-05): o
LS / LS-# / LT-#: o
RMS2600A / 2700G: Side adapters must be purchased separately.
New orthopedic (with RECARO vent): o
RCS: Side adapters must be purchased separately
SP-A / SP-G / SP-G2 / SP-G3 / SP-GT / SP-GT2: Side adapters must be purchased separately
SP-AN / SP-GN / SP-GN 2: Side adapters must be purchased separately
RACER SP-G/A: Side adapters must be purchased separately
AM19 TREND-J AM19 TREND-JJ AM19 TREND-JC: o
AM19 STYLE-J AM19 STYLE-JJ AM19 STYLE-JC: o
AM19 SPORT-J AM19 SPORT-JJ AM19 SPORT-JC: o
AM19 TREND-JS: o
AM19 STYLE-JS: o
AM19 SPORT-JS: o
AM19 TREND-D AM19 TREND-DC: o
AM19 STYLE-D AM19 STYLE-DC: o
AM19 SPORT-D AM19 SPORT-DC MAGNIFICA CL222HV: o
TS-G / RS-G / TS-W / RS-W: Side adapters must be purchased separately
SP-X: o
SR-6 / SR-7 / SR-7F / SR-11: o
Sportster / Cross Sportster: o

The next seat has different consoles on the left and right sides of the vehicle, so the seat cushion side and the center console interfere at the front passenger seat slide position. Sportster interferes up to 10mm from around 50mm from the front end of the slide, and SR-6, 7, and 11 interfere around 3mm from around 20mm from the front end of the slide. SP-# is required for both the driver's seat and the passenger's seat, and the SP-G offset adapter set (6600 yen ) is required for the racer. When installing RS-G/TS-G, if you are more concerned about the steering wheel offset than the sitting height in the driver's seat, you can adjust it by using an optional offset adapter. The RMS can be adjusted to the optimum position (front/rear height, left/right offset 0/5/10mm) with the RMS side adapter (sold separately).
(Caution) This product cannot be attached to seats other than those listed in the matching information below. GR Yaris. Sports frame (with adapter frame) side airbag canceller included. The compatibility of models other than those listed and vehicles equipped with optional accessories has not been confirmed.

Images are for illustration purpose only. Actual product may vary.
